Sega Mega Drive Dual Frequency Oscillator Mod Kit

Mod Kit Includes:

  • 1 x Sega Mega Drive Dual Frequency Oscillator (5V DIL14 Version)
  • 3 x Mounting pins

Features:

  • Stable and accurate clock frequency in both 50Hz and 60Hz console settings
  • Adds an extra layer of compatibility for modern TVs and up-scalers when forcing none standard console regions
  • Compatible with my awesome Mega Drive region mod boards

Out of stock

Email when stock available

SKU: KIT-SMD-DFO Categories: , ,
Component Stock Notice: This product shares components with other products. If buying multiple products that share components, a shared component must not exceed the available quantity.
Components: "PLL - CDCE913 - TSSOP14" (22 available), "XTAL - 27MHZ - HC49S" (4 available), "REG - 1.8V - SOT235" (25 available), "REG - 3.3V - SOT235" (0 available), "LOG - 74LV1T126 - SOT235" (81 available).

Description

Sega Mega Drive Dual Frequency Oscillator Mod Kit

Sega Mega Drive / Genesis Dual Frequency Oscillator (DFO) mod kit is designed to switch the video refresh rate between more accurate and stable 50Hz and 60Hz as compared to running region modified consoles in non-native video refresh rates.

DFO does not change the colour sub-carrier for forced region colour over composite and RF.

It is important that you know what you are doing with these and know their intended purpose and how much benefit this might bring.

5V DIL14

The 5V DIL14 is designed to replace metal can oscillators like those found in Sega Mega Drive / Genesis consoles. It is a direct replacement and has the same footprint as the metal can oscillator.

Additional information

Weight 0.003 g
Product Type Mod Kit
Console Make SEGA
Console Model Mega Drive
Mod Attribute Dual Frequency Oscillator (DFO)
Designed by Micro
Coded by Not Applicable
HSCODE 85437000
